Technical Parameters of Allen‑Bradley 5069‑L310ER
Model: 5069‑L310ER
User Memory: 1 MB
Network Interface: Dual Gigabit EtherNet/IP
Topology: Linear, Star, DLR
USB: USB 2.0 Type‑B (commissioning only)
I/O Platform: Compact 5000 I/O (max 8 local modules)
Programming Software: Studio 5000 Logix Designer
Mounting: DIN‑rail / Panel mount
Max EtherNet/IP Nodes: 24
What is the Allen‑Bradley 5069‑L310ER?
The Allen‑Bradley 5069‑L310ER is a standard PLC from Rockwell Automation CompactLogix 5380 platform, a cost‑effective solution for small‑to‑medium automation projects.
It has dual gigabit EtherNet/IP ports and 1 MB user memory with DLR ring redundancy. Seamlessly expandable with 5069‑series digital and analog I/O modules. Compact and reliable, it is widely used for standalone machines and small production lines as a popular base‑model within CompactLogix lineup.
Key Advantages of 5069‑L310ER
Dual Gigabit Ports for Flexible Networking Dual gigabit EtherNet/IP ports with DLR redundancy. Separate connections for upper‑level and field devices, no extra communication modules needed for fast network recovery.
Compact Size Saves Cabinet Space DIN‑rail mount compact form factor, ideal for cabinets with limited installation space and standalone machines.
Unified Logix Platform for Easy Programming Works with Studio 5000 Logix Designer shared with ControlLogix and GuardLogix. Engineers familiar with Allen‑Bradley can get started quickly.
Flexible Modular I/O Expansion Supports full‑range 5069‑series local digital and analog I/O modules. Adjust I/O points to fit small or moderately complex projects.
What is the difference between 5069‑L310ER and 5069‑L306ER?
Both belong to CompactLogix 5380 series with identical hardware form and I/O expansion capability. The main differences are user memory and maximum EtherNet/IP nodes.
‑ 5069‑L306ER: 0.6 MB user memory, up to 16 EtherNet/IP nodes
‑ 5069‑L310ER: 1 MB user memory, up to 24 EtherNet/IP nodes
Select based on program size, I/O scale and number of field EtherNet/IP devices. Choose 5069‑L310ER for larger programs or more connected devices.
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipment within 3-5 working days.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: How many ports does the 5069‑L310ER have?
A1: It comes with two built‑in gigabit EtherNet/IP ports. Dual‑IP addressing and DLR (Device‑Level Ring) redundancy are supported to satisfy both field‑level and upper‑level communication requirements.
Q2: What software is used for 5069‑L310ER programming?
A2: It uses Rockwell's standard Studio 5000 Logix Designer. The programming framework is fully compatible with the larger ControlLogix platform for high program portability.
Q3: How many EtherNet/IP devices can the 5069‑L310ER support?
A3: It supports up to 24 EtherNet/IP device nodes, sufficient for typical standalone machines connecting drives, servo systems, HMI and I/O modules.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the Allen‑Bradley 5069‑L310ER!
