Eaton
Eaton Industrial Automation Components Supplier for Wholesale and Replacement Procurement
We supply Eaton industrial automation components and electrical spare parts for wholesale purchasing, equipment maintenance, and replacement requirements. Our listed products include NZM3 molded case circuit breakers, PowerXL DE1 variable speed starters, PKZM motor protection circuit breakers, switch disconnectors, and matching accessories.
Specific models include NZMN3-A400, DE1-122D7FN-N20N, PKZM4-40, NZM1-XU208-240AC, and PN2-250.
-
Eaton PN2-250 3P Cost-Effective Switch Disconnector, 250A...● Model Number:Eaton PN2-250read more
● 250A MCCB Industrial Switch | Power Distribution Protection Equipment
● Eaton PN2-250 is a 3-pole molded case switch disconnector of PN2 frame with 250A... -
Eaton NS3-400-NA 4P Switch Disconnector With Neutral Pole...● Model Number:Eaton NS3-400-NAread more
● NZM3 Frame Disconnect Switch
● Eaton NS3-400-NA 3-pole 400A molded case disconnect switch under the NZM3 frame of Eaton NZM series, engineered... -
Eaton N3-400 3P Heavy-Duty Switch Disconnector, 400A Isol...● Model Number:Eaton N3-400read more
● 400A MCCB Industrial Circuit Breaker | High Current Power Distribution Protection
● Eaton N3-400 Molded Case Circuit Breaker, rated at 400A, is designed... -
Eaton N1-125 3P Standard Switch Disconnector, 125A Distri...● Model Number:Eaton N1-125read more
● 125A MCCB Industrial Switch | Power Distribution Protection Equipment
● Eaton N1-125 molded case circuit breaker has a rated current of 125A. It is... -
Eaton NZM1-XU208-240AC AC Undervoltage Release Accessory ...● Model Number:Eaton NZM1-XU208-240ACread more
● 208-240VAC Accessory for NZM1 Series Circuit Breakers
● Eaton NZM1-XU208-240AC is a dedicated undervoltage release accessory for Eaton NZM1... -
Eaton Moeller PKZM4-40 3P 32–40A Class 10 Adjustable Moto...● Model Number:Eaton PKZM4-40read more
● 32-40A Three-phase Motor Switch
● Eaton PKZM4-40 motor protection circuit breaker with adjustable current from 32A to 40A. It integrates overload,... -
Eaton XStart PKZM01-20 3P Push Button MPCB, 12–20A Class ...● Model Number:Eaton PKZM01-20read more
● 16-20A adjustable motor protection switch
● The Eaton PKZM01-20 is a push-button 3-phase MPCB from the xStart series. It features stepless adjustable... -
Eaton PKZM01-16 3P Push-button MPCB, 1–1.6A Class 10 Moto...● Model Number: Eaton PKZM01-16read more
● 10-16A 3-Phase MPCB
● The Eaton PKZM01-16 is a DIN rail mounted push-button motor protection circuit breaker with an adjustable current range of... -
Eaton PKZM01-10 Push-button Motor Protective Circuit Brea...● Model Number:Eaton PKZM01-10read more
● 6.3-10A DIN rail MPCB
● The Eaton PKZM01-10 is a push-button 3-phase motor protector from the xStart series. It features stepless adjustable current... -
Eaton Moeller PKZM01-1.6 Motor-Protective Circuit-Breaker...● Model Number:Eaton PKZM01-1,6read more
● 1-1.6A Low-current MPCB
● The Eaton PKZM01-1,6 is a low-current push-button MPCB from the xStart series, featuring stepless adjustable current ranging... -
Eaton PKZM01-1 3P Push Button MPCB 0.63-1A Motor Protector● Model Number:Eaton PKZM01-1read more
● 0.63-1A, Replacement for Moeller, Mini Motor MPCB
● The Eaton PKZM01-1 is an ultra-low-current push-button MPCB of the xStart series. It features... -
Eaton PKZM0-25 Motor Protective Circuit Breaker (MPCB) 20...● Model Number:Eaton PKZM0-25read more
● 3 Pole 20-25A DIN Rail Motor Protector
● The Eaton PKZM0-25 is a popular motor protection switch within the Eaton xStart series. This 3-pole DIN rail...
1. Eaton Components for Replacement and Industrial Procurement
We support procurement requirements involving:
- Replacement of existing Eaton components in industrial control and power distribution systems.
- Industrial maintenance and repair spare parts.
- Obsolete and difficult-to-source Eaton models.
- Single-unit, small-quantity, and mixed-model purchasing.
- Multi-brand industrial automation and electrical BOM procurement.
Buyers can submit individual part numbers or consolidated BOM lists for sourcing and quotation.
2. Eaton Model Identification and Technical Specifications
NZMN3-A400 Molded Case Circuit Breaker
NZM3 Series · Catalog No. 109670
| Model | NZMN3-A400 |
|---|---|
| Rated current | 400 A |
| Number of poles | 3 |
| Rated voltage | 690 V |
| Frame size | NZM3 |
| Trip technology | Thermal-magnetic |
| Overload current setting | 320–400 A |
| Rated service short-circuit breaking capacity (Ics) | 50 kA at 400/415 V, 50/60 Hz |
| Installation | Fixed |
| Dimensions | 140 × 275 × 166 mm |
| Weight | 6.109 kg |
Terminal connection capacity can reach 240 mm², depending on the cable manufacturer and terminal configuration.
DE1-122D7FN-N20N Variable Speed Starter
| Model | DE1-122D7FN-N20N |
|---|---|
| Product family | PowerXL DE1 |
| Supply voltage | 230 V AC |
| Input phase | Single-phase |
| Rated operating current | 2.7 A |
| Motor power | 0.55 kW |
| Horsepower | 0.5 HP |
The complete model number is essential for identification. These specifications follow the corresponding manufacturer product record, rather than conflicting electrical values in the original product listing.
PKZM4-40 Motor Protection Circuit Breaker
| Model | PKZM4-40 |
|---|---|
| Adjustable current range | 32–40 A |
| Connection | Screw connection |
| Terminal protection | IP00 |
NZM1-XU208-240AC Undervoltage Release
| Model | NZM1-XU208-240AC |
|---|---|
| Catalog number | 259442 |
| Accessory type | Undervoltage release |
| Control voltage | 208–240 V AC |
| Compatible breaker series | NZM1(-4), N(S)1(-4) |
PN2-250 Switch Disconnector
| Model | PN2-250 |
|---|---|
| Number of poles | 3 |
| Rated current | 250 A |
| Connection | Screw connection |
| Frame compatibility | NZM2 |
3. Eaton Product Selection and Available Models
Our Eaton product listings cover the following categories and models:
Circuit Breakers: NZM series molded case circuit breakers, including NZMN3-A400, NZMN3-A320, NZMN2-A250, NZMN1-A125, and NZMN1-A100.
Variable Speed Starters: PowerXL DE1 models, including DE1-122D7FN-N20N, DE1-345D0FN-N20N, and DE1-34016FN-N20N.
Motor Protection Circuit Breakers: PKZM series, including PKZM4-40, PKZM01-20, PKZM01-16, and PKZM01-10.
MCCB Accessories: NZM series accessories, including NZM1-XU208-240AC.
Switch Disconnectors: N, NS, and PN series models, including PN2-250, NS3-400-NA, N3-400, and N1-125.
Availability, product condition, and configuration are confirmed against individual part numbers and order requirements.
4. Product Inspection and Supply Support
We support industrial automation buyers with product identification, sourcing coordination, and order verification.
Our services include:
Part number verification: Checking model numbers, quantities, product versions, and accessory requirements against purchasing lists.
Product condition confirmation: Identifying available conditions, including new, unused surplus, and open-box products.
Visual inspection: Providing product photographs, nameplate details, serial-number photographs, and selected inspection records where available.
BOM procurement: Consolidating multiple models and brands into one purchasing requirement.
Obsolete parts sourcing: Searching available supply channels for discontinued and difficult-to-source industrial automation components.
International shipping coordination: Supporting export shipments through available logistics services.
Our broader industrial electrical support also includes control cabinet and distribution box assembly, wiring harness processing, terminal assembly, and functional testing. These are company-level services, separate from Eaton product manufacturing or modification.
5. Eaton Spare Parts and Mixed-Model Procurement
We accept individual part-number inquiries as well as consolidated purchasing lists.
Our procurement services support:
- Single-unit and small-quantity inquiries.
- Multiple Eaton models in one order.
- Mixed-brand industrial automation BOMs.
- Replacement-part and obsolete-model sourcing.
- Product photographs and condition confirmation before shipment.
A 12-month warranty is listed for relevant products on our product pages. Applicable warranty terms depend on the specific product and order.
6. Request an Eaton Quotation
Send us your Eaton part numbers and required quantities for a product and supply quotation.
If the complete model number is unavailable, you can send a nameplate photograph, product image, or existing spare-parts list.
We will use the available identification details to check the corresponding model, product condition, sourcing options, and quotation requirements.
