BECKHOFF EL5001 Technical Specifications
Model:BECKHOFF EL5001
Encoding type: Gray code, Binary code
Maximum baud rate: 1 MHz
Maximum data length: 32 bits
Signal type: Differential signal (RS422), Data signals (D+/D-), Clock signals (Cl+/Cl-)
Communication Protocol: EtherCAT
Mounting Type: Standard 35mm DIN-Rail Mounting
Encoder supply: 24 V DC (directly via power contacts), optional 5 V DC (requires EL9505)
Operating power supply: 24 V DC (via E-bus supply)
Electrical isolation: 500 V (E-bus and field side isolated)
Status indicators: LED indicators for power, operation, and data transmission status
Operating Temperature:-25℃ ~ +60℃
Protection Rating: IP20
What is BECKHOFF EL5001?
Our BECKHOFF EL5001 is a single-channel SSI encoder interface module, supporting 24V power supply and a communication speed of up to 1 MHz. It's very easy to use and can transmit position data reliably and at high speed to the EtherCAT system, making it ideal for various position measurement applications such as automation equipment, conveyor lines, or servo control systems.
Why Choose Beckhoff EL5001?
1. Single-channel SSI master design, fully supports single-turn and multi-turn absolute encoders, no extra converter required, reducing system integration cost.
2. 1 MHz high-speed data transmission, enabling fast data acquisition to meet position feedback requirements of high-speed motion equipment.
3. Direct 24V power supply, no additional encoder power module needed, greatly simplifying system wiring.
4. Encoder format compatible: Supports Gray code and binary code, with flexible data length adjustable up to 32 bits.
EL5001 Application Scenarios
The EL5001 is mainly used for collecting position data and is widely used across many types of equipment. For example, it's essential for position feedback in servo motors, machine tools, packaging machines, conveyor systems, as well as angle and tracking feedback in wind power and photovoltaic systems.
Design Highlights
Improve efficiency
● Material:The housing is made of durable engineering plastic, resistant to wear and aging, and also dustproof and moisture-resistant, so it can handle everyday bumps and dusty environments in workshops. The internal PCB uses high-temperature industrial-grade materials, with solid component soldering, allowing stable long-term operation in both high and low temperature conditions, ensuring a long service life.
● Appearance:Standard slim modular design with a 12 mm ultra-thin width, featuring a clean and compact square structure. The clearly visible status indicators make it easy to monitor the operating status at a glance.
● Design:The design is well-suited for on-site operation. It uses a standard 35 mm DIN rail snap-on installation, making assembly and removal very easy without any extra tools. The terminal layout is clearly divided, and the SSI encoder interfaces (D+/D-, Cl+/Cl-) are clearly labeled, so even beginners can complete the wiring quickly.
Aftersales Support
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipped the same day.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: What types of encoders does the BECKHOFF EL5001 support?
A1:This module supports both single-turn and multi-turn absolute encoders, compatible with Gray code and binary code formats. The data length is flexible, up to 32 bits, making it suitable for most industrial-grade SSI encoders.
Q2: How does the EL5001 power the encoder?
A2: The module provides 24V DC directly to the encoder through its power contacts, so no extra encoder power supply is needed. If a 5V DC encoder is required, the Beckhoff EL9505 power terminal can be used.
Q3: What is the maximum data transfer rate?
A3: The maximum baud rate is 1 MHz, allowing fast position data acquisition to meet the real-time control needs of high-speed motion equipment.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the BECKHOFF EL5001!
