Technical Parameters of Schneider TM3SAF5R
Product Series: Modicon TM3
Product Type: Safety Expansion Module
Model: TM3SAF5R
Quantity of Safety Functions: 1 set
Safety Level: Cat.4 / PL e (EN ISO 13849-1), SIL CL3 (IEC 62061)
Safety Inputs: 2 channels, 24V DC
Safety Outputs: 3 parallel relay outputs (Normally Open)
Max Current per Output: 6A
Supply Voltage: 24V DC
Compatible Controllers: Modicon M221 / M241 / M251 series PLC Response Time: ≤40ms
Status Indication: Front LED channel indicators
What is Schneider TM3SAF5R?
Schneider TM3SAF5R is a 24V DC safety relay expansion module of TM3 series. It rapidly cuts off machine power once hazardous conditions are detected, including:
1.Pressed emergency stop button
2.Opened safety guard door
3.Triggered safety light curtain area
4.Malfunction of external safety devices
This module adopts dual-channel safety signal detection and cuts off equipment via built-in safety relays to achieve compliant machine stop meeting Cat.4 PL e safety standards.
Typical Application Scenarios
The TM3SAF5R suits safety control for all kinds of small and medium automated machinery:
1.Emergency Stop Monitoring: Collect dual-channel emergency stop signals and cut off power rapidly when hazards arise
2.Safety Door Monitoring: The machine shuts down right away once protective doors are opened
3.Safety Light Curtain Matching: Trigger safety protection when personnel intrusion is detected
4.Custom Machine Retrofit: Upgrade safety features for packaging machines, assembly equipment and conveyor lines
Why Choose Schneider TM3SAF5R?
We supply genuine Schneider TM3SAF5R safety modules for industrial machine maintenance, system upgrades and project procurement.
Our advantages:
✔ Guaranteed original authentic quality
✔ Support bulk orders
✔ Fast quotation reply
✔ Rich experience in supplying industrial automation products
If you are looking for Schneider TM3SAF5R safety modules, 24V DC safety relay modules or Modicon TM3 safety expansion modules, the TM3SAF5R is a dependable solution for industrial safety control systems.
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipment within 3-5 working days.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1:Which PLCs are compatible with TM3SAF5R?
A1: As an expansion module of Schneider TM3 series, it works with all Modicon M221, M241 and M251 PLCs and can be installed directly for expansion.
Q2: What safety levels can this module reach?
A2: TM3SAF5R achieves Cat.4 / PL e under EN ISO 13849-1 and SIL CL3 under IEC 62061, meeting safety compliance requirements for most small and medium-sized machines.
Q3: What safety functions does it support?
A3: It covers common single-group safety applications including emergency stop monitoring, safety gate monitoring and safety light curtain connection. It adopts dual-channel input monitoring and comes with complete fault diagnosis functions.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the Schneider TM3SAF5R!
