Technical Parameters of Allen-Bradley 2198-S086-ERS3
Model: 2198-S086-ERS3
Continuous Current: 43 A RMS
Continuous Output Current: 60.8 A 0-pk
Peak Current: 86 A RMS
Peak Output Current: 121.6 A 0-pk
Continuous Power Output: 29.7 kW
Input Bus Voltage: 324…528V RMS, 3-phase
DC Input Range: 458…747V DC
Rated Control Power Supply: 24V DC
PWM Frequency: 4 kHz
Max Velocity Loop Bandwidth: 400 Hz
Product Introduction: Allen‑Bradley 2198-S086-ERS3
Allen-Bradley 2198-S086-ERS3 is a Rockwell Kinetix 5700 single-axis inverter for large machines and high-power multi-axis servo applications.
Different from Kinetix 5500 H-series drives, this Sxxx single-axis module must pair with Kinetix 5700 DC Bus Supply to form a complete servo system.
It provides 43 A RMS / 60.8 A 0-pk continuous current, 86 A RMS / 121.6 A 0-pk peak current, with 29.7 kW continuous power at 324–528V 3-phase input.
Ideal for high-power multi-axis EtherNet/IP motion control.
Why Choose Allen-Bradley 2198-S086-ERS3?
● 43A continuous output and 86A peak current, sufficient power for heavy transient loads
● 29.7kW power rating for large load applications
● Kinetix 5700 modular single-axis design for flexible configuration
● 85mm narrow width to save cabinet space
● Built-in ERS3 hardwired safety function
● Compatible with Kinetix 5700 multi-axis DC Bus systems
ERS3 vs ERS2 Key Differences
Many customers get confused between these two safety versions of Kinetix 5700. They adopt different safety solutions for different applications:
● 2198-S086-ERS3 (This model): Hardwired STO. Safety signals run via independent hardware circuits instead of EtherNet/IP. Strong anti-interference performance for heavy machinery, precision equipment, harsh environments and high safety requirements.
● ERS2 Version: CIP Safety over network. Safety signals transmitted over Ethernet cables to reduce hardwiring work. Suitable for multi-axis systems with clean working conditions, where simplified wiring is preferred.
