BECKHOFF EL9070 Technical Specifications
Model:BECKHOFF EL9070
Shield connection points: 8 ×
Maximum current load: ≤ 10 A
Communication Protocol: EtherCAT
Mounting Type: Standard 35mm DIN-Rail Mounting
Rated voltage: Any voltage up to 230 V AC
Electrical isolation: 500 V AC isolation between the E-bus and field side
Protection Rating: IP20
What is BECKHOFF EL9070?
BECKHOFF EL9070 is a shield terminal module specifically designed for EtherCAT I/O systems, mainly used to handle the grounding of various shielded cables in industrial environments. The module comes with 8 built-in terminal points that can be directly connected to the mounting rail potential, without the need for additional terminal blocks or complex wiring. During installation, the shield can be connected directly, making the process simple and helping engineers save significant time on installation and wiring.
Why Choose Beckhoff EL9070?
● The module comes with 8 built-in terminal points, allowing multiple shielded cables to be grounded with a single module. This keeps wiring neat and helps reduce electromagnetic interference, ensuring more stable system operation.
● No additional equipotential terminal blocks are required, which lowers component costs and saves space inside the control cabinet.
●The EL9070 requires no additional parameter configuration and doesn't need any setup in TwinCAT or other software. Just connect it, and it's ready to use-saving you the hassle of complicated settings.
EL9070 Application Scenarios
The EL9070 is suitable for a wide range of industrial automation applications, including production lines, robot safety control systems, machine protection systems, and PLC safety expansion modules that require safe digital outputs. Whether for new installations or equipment upgrades, it helps improve overall system safety and operational reliability.
Design Highlights
Improve efficiency
● Material:The module housing is made of industrial-grade PC material, which is sturdy and durable with flame-retardant properties. It can withstand bumps, dust, and humidity commonly found in workshop environments. The internal shielding part uses high-purity copper in a seamless, one-piece design, offering excellent conductivity and low contact resistance, ensuring stable and reliable grounding performance over long-term use.
● Appearance:The EL9070 has 8 shielded connection points arranged neatly with clear labels, making wiring quick and easy. Without any extra LED indicators, it focuses purely on shield grounding, keeping costs low while improving reliability.
● Design:The terminal design is simple and practical, providing a secure connection that is not easily loosened after wiring. Even in environments with continuous operation or vibration, it maintains a stable connection. The internal structure is straightforward, without complex electronic components, making it reliable for everyday use and reducing maintenance requirements over the long term.
Aftersales Support
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipped the same day.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: Why does the EL9070 not require additional terminal blocks?
A1: The EL9070 achieves PE grounding directly through the standard 35 mm DIN rail. It has 8 built-in shield connection points that allow direct connection of shielded cables, eliminating the need for additional equipotential terminal blocks. This helps save both cost and installation space.
Q2: What are the advantages of the EL9070's seamless copper surface?
A2: The seamless copper surface provides low contact resistance and more effective shielding grounding. It helps discharge interference currents efficiently and forms a reliable shielding barrier between adjacent EtherCAT terminals, significantly improving overall EMC performance.
Q3: How much current can the EL9070 carry?
A3: The maximum current load is up to 10 A, and the rated voltage supports up to 230 V AC, meeting the grounding requirements of most industrial shielded cable applications.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the BECKHOFF EL9070!
