BECKHOFF EL9100 Technical Specifications
Model:BECKHOFF EL9100
Maximum current load: 10 A
Communication Protocol: EtherCAT
Mounting Type: Standard 35mm DIN-Rail Mounting
Rated voltage: 24 V DC (allowable fluctuation: -15% / +20%)
Electrical isolation: 500 V AC (E-bus / field side)
Protection Rating: IP20
What is BECKHOFF EL9100?
BECKHOFF EL9100 is a power feed module designed for EtherCAT I/O systems. Its main function is to provide a stable 24 V DC power supply and distribute power potential properly to each terminal module. It can be installed flexibly between modules, allowing different potential groups to be created easily to meet multi-load power demands in the field, without affecting E-bus communication.The module also comes with a built-in power status LED indicator, so the operating status can be checked at a glance. With a pure hardware design and no need for software configuration, it works right after wiring, making it a convenient solution for industrial automation equipment and smart factory applications.
Why Choose Beckhoff EL9100?
● Fast response, ensuring stable and reliable transmission of control signals on site.
● Compact modular design, allowing dense installation without taking up much space.
● No extra address settings required-just plug in and use, saving time and hassle during setup.
● Sturdy and durable construction, providing stable performance even during long-term operation.
● Highly compatible, easily integrates with existing EtherCAT systems.
EL9100 Application Scenarios
The EL9100 provides ample power, supports potential isolation, and offers flexible installation. It is widely used with automation production lines, robots, PLC expansion modules, and other equipment. Suitable for both new projects and equipment upgrades, it helps ensure stable system operation.
Design Highlights
Improve efficiency
● Material:The EL9100 uses a thick, industrial-grade circuit board inside, built solidly to handle 10A high-current power supply requirements. It runs stably even under full load for long periods, with minimal risk of overheating or aging. Coupled with high-quality isolation components, it provides reliable interference protection and potential isolation, making it very dependable in the field.
● Appearance:The compact housing allows it to be installed closely alongside other modules, saving space inside the control cabinet. Wiring is also easier to organize, keeping the layout neat and clean. It is especially suitable for use in space-limited control cabinets.
● Design:The module's overall design is highly practical and tailored to industrial use. Its standard DIN rail clip structure allows for quick installation or removal by hand, with no complex setup or software configuration required-just plug and play. It can also be installed at any position within the EtherCAT terminal chain, offering flexible system expansion.
Aftersales Support
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipped the same day.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: What is the purpose of electrical isolation in the EL9100?
A1: The 500 V electrical isolation between the E-bus and field side helps eliminate interference between different potential zones, protects downstream precision instruments and control systems, and improves overall system stability.
Q2: What is the function of the EL9100 power indicator light?
A2: The green power LED provides real-time status indication of the module, allowing on-site operators to quickly check whether the power supply is normal, reduce troubleshooting time, and improve system availability.
Q3: Where can the EL9100 be installed in the EtherCAT terminal chain?
A3: It can be installed at any position within the I/O module chain. It can be used to create a new potential group or provide additional power to high-load modules on the right side. The installation position is flexible and not restricted by system topology.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
