Eaton FD3060: Direct Drop-In Replacement for Cutler-Hammer & Westinghouse Old Units
Looking for reliable FD3060 replacement parts? This circuit breaker is fully compatible with original old FD3060 breakers from Cutler-Hammer and Westinghouse. It features an exact 1:1 dimensional match and enables direct drop-in replacement. Its mounting holes and terminal positions align perfectly with older units. No cabinet modifications or rewiring are required when swapping out the old breaker for this new one, making installation quick and hassle-free.
Eaton FD3060 Features & Benefits
● It offers stable protection and solid durability with dual thermal-magnetic protection. It cuts power gradually under circuit overload and trips instantly during short circuits to prevent damage to wires and equipment.
● Multiple mounting options fit most setups; it accepts both copper and aluminum wires and works with all standard cabinets as well as DIN rails, bringing great convenience to installation.
● Compatible with both AC and DC circuits, one unit replaces two separate breakers. Rated for 600V AC and 250V DC, so you don't need to purchase two different models, saving you plenty of trouble.
Product Specifications
● Model:Eaton FD3060
● Number of Poles: 3 Pole
● Rated Current: 60A
● Rated Voltage: 600VAC / 250VDC
● Applicable Frequency: 50/60Hz
● Wiring Method: Load-side terminals, compatible with copper and aluminum cables
● Certifications: UL Listed, CSA Certified, complies with Federal Specification W-C-375b
● Mounting Type: Panel bolt mounting / DIN rail mounting
FD3060 Replacement Options
If your equipment uses Cutler-Hammer or Westinghouse FD3060 circuit breakers, this model supports direct drop-in replacement. It features an exact 1:1 match in dimensions and mounting specifications with zero modifications needed.
Interchangeable Models of the Same FD Frame
Improve efficiency
● FD3080: 80 Amp variant, sharing the identical FD frame dimension with FD3060, only differing in rated current capacity
● FD3050: 50 Amp version, identical frame size with a different rated current
● FD3070: 70 Amp version, sharing the same frame as FD3060 with different current parameters
Aftersales Support
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipment within 3-5 working days.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: Can FD3060 be used for DC circuits?
A1: Yes. The FD3060 is rated at 250 VDC with an interrupting rating of 10 kA. It works for both 600 VAC industrial power distribution systems and 250 VDC control circuits.
Q2: What wire gauges are compatible with the FD3060?
A2: It accepts copper and aluminum cables ranging from 14 AWG to 1/0 AWG, meeting the wiring requirements of most industrial branch circuits.
Q3: Can the trip current of this circuit breaker be adjusted?
A3: No. The FD3060 features a fixed thermal-magnetic trip design with factory-set trip parameters that cannot be adjusted on site. If adjustable trip settings are required, you may opt for Eaton FDE series circuit breakers with electronic trip units.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the Eaton FD3060!
