FD3100: Ideal Replacement for Obsolete Cutler-Hammer and Westinghouse Circuit Breakers
Many field maintenance technicians and equipment service clients are searching for FD3100 replacement parts. Original Cutler-Hammer and Westinghouse FD3100 circuit breakers installed in older electrical panels are hard to source once they fail. Our Eaton FD3100 is a dedicated direct drop-in replacement. Eaton acquired the power distribution divisions of Cutler-Hammer and Westinghouse years ago, so their frame specifications are fully interchangeable. Simply remove the old breaker and fit this new unit straight into place!
Eaton FD3100 Features & Benefits
● Suitable for 600V AC and 250V DC circuits with dual protection against overload and short circuit, applicable to industrial power distribution cabinets and motor control circuits.
● It carries both UL and CSA certifications as well as an HACR rating specifically for HVAC equipment. Compatible with Eaton Series C panelboards and MCC motor control centers, it fully meets compliance requirements for project acceptance.
● This breaker serves as a direct replacement for original Cutler-Hammer and Westinghouse FD3100 circuit breakers with an exact 1:1 dimensional match, enabling drop-in installation without cabinet modification or rewiring.
Product Specifications
● Model:Eaton FD3100
● Number of Poles: 3 Pole
● Rated Current: 100A
● Rated Voltage: 600VAC / 250VDC
● Interrupting Capacity 240VAC:65kA, 480VAC:35kA, 250VDC:10kA
● Compatible Wire Size: 14 AWG ~ 2/0 AWG copper or aluminum cables
● Series: Eaton Series C FD Frame
Application
●Industrial production scenarios: Provides overload and short-circuit protection for production line control cabinets, machine tools, conveyor equipment and motor circuits; applicable to branch selective protection inside MCC motor control centers, switchgears and distribution panels.
●Commercial building power distribution: Matches central air conditioning, lighting and general power circuits in shopping malls, office towers and hotels.
●OEM equipment supporting parts: Serves as original matched components for automated machinery, packaging machines and refrigeration & HVAC systems.
●Old power system renovation & maintenance: Ideal for factory electrical upgrades, faulty breaker replacement and old cabinet refurbishment projects.
Compatible Cabinet Range
Improve efficiency
● Standard fitment: Designed to be compatible with Eaton Series C panelboards, switchgear and MCC motor control centers
● Cross-brand compatibility: Matches most Westinghouse and Allen‑Bradley motor control units adopting the FD frame dimension
● Easy installation: No extra custom mounting accessories needed, offering high versatility for various system configurations
Aftersales Support
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipment within 3-5 working days.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: Does this circuit breaker carry an HACR rating and can it be used for air conditioning equipment?
A1: Yes. The FD3100 features an HACR rating dedicated to HVAC applications. It can be directly installed for branch circuit protection of heating, air conditioning and refrigeration equipment, complying with power distribution standards for HVAC systems.
Q2: What circuit protection functions does the FD3100 offer?
A2: The FD3100 adopts a fixed thermal-magnetic trip design with dual protection functions. It provides delayed overload protection to prevent nuisance tripping during mild circuit overloads, plus instantaneous short-circuit protection that immediately disconnects power when a short circuit occurs. It delivers reliable safety protection for motor circuits and distribution branch circuits.
Q3: Are the mounting dimensions interchangeable among the FD3100, FD3080 and FD3125?
A3: Yes, they are fully interchangeable. The FD3080 (80A), FD3100 (100A) and FD3125 (125A) all belong to the Eaton FD frame series and share identical mounting dimensions and cutout sizes, differing only in rated current. Switch to the FD3080 for reduced load requirements or the FD3125 for distribution capacity expansion, with no cabinet modifications needed at all.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the Eaton FD3100!
