Technical Parameters of Schneider TM241CE40R
Model: TM241CE40R
Total I/O: 40 points
Digital Inputs: 24 channels
Fast Inputs: 8 channels
Standard Inputs: 16 channels
Digital Outputs: 16 channels
Fast Outputs: 4 channels (PNP transistor)
Relay Outputs: 12 channels
Relay output current: 2 A (resistive load)
Fast transistor output current: 0.1A(PTO mode) / 0.5A(standard mode) Input voltage: 24 V DC
Power supply voltage: 100‑240 V AC
Permissible supply range: 85‑264 V
Ethernet: Supported
Product Overview of TM241CE40R
Schneider TM241CE40R is a compact PLC from Schneider Electric Modicon M241 series, widely used for machinery automation and small‑to‑medium industrial control projects.
It delivers 40‑point I/O, including 24 digital inputs and 16 digital outputs. Among them are 8 fast inputs and 16 standard inputs. The outputs adopt mixed configuration: 4 fast transistor outputs plus 12 relay outputs. Each relay channel is rated at 2 A for various industrial switching loads.
Built‑in Ethernet, dual serial ports and Mini‑USB programming port enable easy connection to HMIs, host systems and other industrial devices.
Product Features of Schneider TM241CE40R
● 40‑point I/O for small‑to‑medium machine control
● Built‑in Ethernet for convenient device networking
● High‑speed I/O for basic motion control
● 12‑channel relay outputs for broad load compatibility
Interfaces & Mechanical Design of TM241CE40R
On‑board components:
● Run/Stop switch
● SD card slot
● RTC battery holder
● Cartridge slot
● I/O status LED indicators
● Mini‑B USB programming port
● Ethernet port
● Two serial communication ports
● 35 mm DIN‑rail clip
All interfaces are integrated on the controller body, easing cabinet wiring and simplifying troubleshooting and programming work.
Quantity available: In stock.
01
Warranty: 12 months.
02
Lead time: Shipment within 3-5 working days.
03
Terms of payment: T/T. RMB (CNY) support.
04
Courier partners: FedEx, DHL, UPS, TNT, EMS, SF express.
05
FAQ
Q1: Is TM241CE40R relay output or transistor output?
A1: It adopts mixed‑output design. Among the 16 outputs, 12 are relay outputs and 4 are fast transistor outputs. Relay channels are for general‑purpose loads, while transistor channels support high‑speed pulse motion control.
Q2: How many I/O points does TM241CE40R have?
A2: Total onboard I/O is 40 points, including 24 digital inputs and 16 digital outputs, sufficient for most small‑to‑medium machinery projects.
Q3: Does this PLC support Ethernet communication?
A3: Yes. TM241CE40R is equipped with an onboard RJ45 Ethernet port supporting Modbus TCP. It can connect to HMIs, host systems and industrial networks for device networking and remote commissioning.
Q4: How can I place an order or apply for bulk purchase discounts?
A4: Send your required order quantity via email to Irene8866@163.com, or leave us a message on WhatsApp (+86 18950163907). We will reply within 24 hours with formal quotation and stock confirmation.
For more product information, please contact our professional sales team to obtain the latest pricing and stock information for the Schneider TM241CE40R!
